Cub Cadet XT2-LX 46 13APA1TNA10 1 / 5

Cub Cadet XT2-LX 46 13APA1TNA10

Product number: 13APA1TNA10

$3,299.00 $3,799.00

Special Online Price!

In Stock

Product Brand: Cub CadetProduct Type: Lawn & Garden Tractor

Have Questions?

Our experts are here to answer your questions.

Contact Us+1 404-301-0719

Store pickup and delivery available — choose at checkout.

Specifications

General

Product Number:
13APA1TNA10
Brand:
Cub Cadet
Product Type:
Lawn & Garden Tractor

Engine

Engine:
Kohler KT722-3108
Engine Displacement:
747cc
Fuel Tank Capacity:
3.0 gal.
Cylinders/Material:
Twin Cast Iron
Engine Start:
Key
Engine Oil Capacity:
2 qts.
Lubrication:
Fully pressurized
Battery:
12V 210 cold crank amps
Battery Type:
AGM (absorbent Glass Mat)
Charging System:
12 Amp Regulated
Choke:
Separate Choke
Oil Filter:
Yes

Drive System

Transmission:
Hydrostatic, foot
Forward Speed:
5.5 MPH
Reverse Speed:
3 MPH
Rear Axle:
1"
Transmission Housing:
Aluminum
Transmission Type:
Tuff Torq K46

Cutting Deck

Deck Cutting Width:
46"
Cutting Modes:
Discharge/mulch/bagging
Deck Wash:
Included
Deck Attach/Removal:
QuickAttach™ (no tools required)
Deck Engagement (PTO):
Electric
Blade(s):
2
Deck Lift:
Manual
Cutting Height Range:
1" - 4"
Anti-Scalping:
2 ball/2 Narrow
Deck Positions:
12 positions

Chassis

Frame:
Robotically welded
Front Axle(s):
Heavy duty Cast iron
Turning Radius:
16"
Front Tires:
15"x6"-6"
Rear Tires:
20"x8"-8"
Tire Tread:
Multi-Trac
Rear Tow Hitch:
Included
Corrosion Protection:
E-coating

Controls

Cruise Control:
Soft touch engagement
Brakes:
Disc
Direction:
NEW optimized steering system, manual sector and pinion
Headlight(s):
2 - LED High Illumination

Comfort

Seat Type:
Cub Comfort™ high-back seat
Arm Rests:
Comfort
Seat Suspension:
Seat spring
Seat Adjustment:
Lever
Floor Mats:
Traction Pad
Seat adj:
10 degree incline and slide

Additional Specifications

Mulch Kit:
Optional
Discharge Chute:
Included
Cup Holder:
Included
Operator Presence System:
Included
Bagger:
Optional
Hour Meter:
Yes

Warranty

Residential Warranty:
3-year/unlimited hour warranty
Frame Warranty:
5-year/unlimited hour warranty
Front Axle Warranty:
5-year/unlimited hour warranty
Trans Fluid:
TT-187Q899000

Maintenance Parts

Air Filter:
16 883 04-S1 OR 490-200-K059
Oil Filter:
52 050 02-S
Engine Oil:
25 357 65-S OR 490-000-C044
Fuel Filter:
24 050 13-S1
Spark Plug:
25 132 14-S
Deck Belt:
954-05087A OR 490-501-C077
Drive Belt:
954-05027B OR 490-501-C061
Blades Order 2:
742P05510 OR SET 490-110-C192
Xtreme Blades:
742P05510-X OR SET 490-110-C203
Ignition Key:
925-1745A

Key Features

  • A strong 23 HP Kohler® engine delivers reliable power to tackle your yard.
  • 46-in. heavy-duty fabricated AeroForce™ deck cutting system that has been tested and proven to deliver a best-in-class cut, meaning fewer clumps and stragglers, finer clippings and increased evenness.
  • Tuff Torq Hydrostatic transmission, no shifting, just push the pedal and go.

Product Manuals

No confirmed manuals are currently available for this product. Browse all product manuals or ask our team.
