Cub Cadet XT1-LT 42 13AKA9TSA10 1 / 6

Cub Cadet XT1-LT 42 13AKA9TSA10

Product number: 13AKA9TSA10

Non-current model. The manufacturer no longer produces this model. Contact us for availability — and we can help with parts and service — contact us.

Product Brand: Cub CadetProduct Type: Non-Current Models

Have Questions?

Our experts are here to answer your questions.

Contact Us+1 404-301-0719

Specifications

General

Product Number:
13AKA9TSA10
Brand:
Cub Cadet
Product Type:
Non-Current Models

Engine

Engine Brand:
Kohler®
Engine Model:
5400 Series
Engine Number:
KS595-3018
Engine Displacement:
541cc
Engine Output:
19.5HP
Starter Type:
Electric
Fuel Tank Capacity:
3.0 gal.
Cylinders;:
Single
Engine Start:
Ignition Key
Engine Oil Capacity:
2.0 qt.
Lubrication:
Fully pressurized
Charging System;:
12 amp regulated
Fuel Gauge;:
No
Governor:
Mechanical
Choke:
Choke-a-matic
Air Filter:
Dual element
Oil Filter:
Yes
Fuel Delivery:
Carburetor

Battery

Battery:
230 CCA
Battery Type:
AGM (Absorbent Glass Mat)
Battery Voltage:
12V

Drive System

Transmission:
Tuff Torq® TL-200
Forward Speed:
5.5 MPH
Reverse Speed:
3 MPH
Rear Axle:
3/4"
Drive System:
Hydrostatic
Transmission Control:
Foot Pedal
Transmission Housing:
Aluminum
Rear Differential Lock:
No

Cutting Deck

Cuting Width:
42 in
Deck Wash:
Yes
Deck Material:
13-gauge steel
Deck Engagement:
Manual
Deck Construction:
Stamped
Blade(s):
Two
Deck Lift:
Manual
Cutting Height Range:
1" - 4"
Anti-Scalping:
2 wheels
Deck Positions:
12

Warranty

Warranty:
3-year unlimited hours
Frame Warranty:
5-year unlimited hours
Front Axle Warranty:
5-year unlimited hours
Deck Shell Warranty:
Lifetime limited
Commercial Warranty;:
No

Chassis

Frame:
Robotically welded
Turning Radius:
16"
Bumper:
No
Rear Tow Hitch:
Yes
Corrosion Protection:
Yes
Front Pivot Bar:
Cast iron

Controls

Cruise Control:
Yes
Brakes:
Disc

Comfort

Seat Type:
15" high-back
Armrests:
No
Seat Adjustment:
Lever
Floor Mats:
Rubber

Wheels

Bearing Type:
Poly Bushing
Rear Tires:
20"x 8"-8"
Front Tires:
15"x 6"-6"
Tire Tread:
Turf Saver

Additional Specifications

Mulch Kit:
Separately
Headlight(s):
Dual-LED
Cup Holder:
Yes
Operator Pres Sys:
Yes
Model #:
13AKA9TSA10

Specifications

Series:
XT1® Enduro Series™

Maintenance Parts

Air Filter:
22-883-01-S1 OR 490-200-K072
Oil Filter:
12 050 01-S
Fuel Filter:
25 050 21-S
Spark Plug:
25 132 28-S OR DCPR7E 490-250-K020
Deck Belt:
954-05021 OR 490-501-C062
Drive Belt:
954-05027B OR 490-501-C061
Blades Order 2:
742P05177 OR SET 490-110-C191
Xtreme Blades:
742P05177A-X OR SET 490-110-C202
Ignition Key:
925-1745A

Key Features

  • The Cub Cadet XT1 LT42 is powered by a Kohler single cylinder 541 cc engine 42-inch stamped, 13-gauge, twin-blade deck with 12 cutting positions.: Equipped with an optimized steering system for responsive handling to give a 16-inch turn radius a zero-turn feel. 3-year/no hour limit warranty (includes powertrain) and 5-year chassis and front axle unlimited hours. Ideal for mowing up to 1.5 acres of mostly flat terrain and a few obstacles. Tuff Torq foot controlled hydrostatic transmission, no shifting - just push the pedal and go

Product Manuals

No confirmed manuals are currently available for this product. Browse all product manuals or ask our team.
