Cub Cadet Pro Z 160 S KW 53TIEFJU050
Product number: 53TIEFJU050
Non-current model. The manufacturer no longer produces this model. Contact us for availability — and we can help with parts and service — contact us.
Product Brand: Cub CadetProduct Type: Non-Current Models
Have Questions?
Our experts are here to answer your questions.
Product Description
PRO Z 160 S KW
Specifications
General
- Product Number:
- 53TIEFJU050
- Brand:
- Cub Cadet
- Product Type:
- Non-Current Models
Engine
- Engine Brand:
- Kawasaki®
- Engine Model:
- FX730V-BS28
- Engine Displacement:
- 726cc
- Engine Output:
- 23.5HP
- Fuel Tank Capacity:
- Dual 3.5 gal. US (13.25 L)
- Engine Start:
- Ignition Key
- Engine Oil Capacity:
- 2.0 qt. US (1.89 L)
- Lubrication:
- Fully pressurized
- Charging System:
- 15 amp regulated
- Fuel Gauge:
- No
- Choke:
- Separate Choke
- Air Filter:
- High Density
- Oil Filter:
- Yes
Drive System
- Transmission:
- 12cc Hydro-Gear® ZT 3400 with charge pumps
- Forward Speed:
- 9.5 mph
- Reverse Speed:
- 4.5 mph
Cutting Deck
- Deck Cutting Width:
- 60 in
- Deck Engagement (PTO):
- electronic fingertip engagement pto
- Deck Construction:
- Floating, fabricated 10ga. (.135”) steel shell (e-coated)
- Spindle Construction:
- 5" sealed cast aluminum housing (maintenance-free)
- Blade(s):
- 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range;:
- 1” to 5” in 1/4” increments
- Anti-Scalping:
- 4 Front HD w/ Bushings & Grease Zerk
- Deck Positions:
- Hand Lever / 15 position / spring assist
Warranty
- Warranty:
- 4-year/500-hour limited residential warranty
- Commercial Warranty:
- 2-year limited commercial warranty (no hour limitations)
Chassis
- Frame:
- Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
- Front Axle:
- 2" x 3" solid steel
- ROPS:
- 2" x 2" quick-latch tool-less foldable 3 position
- Bumper:
- 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Yokes:
- 3/8" thick steel with sealed ball bearing front yokes
Controls
- Cruise Control:
- Standard - Foot operated pedal engagement
- Brakes:
- Foot-operated pedal
- Steering Control:
- High Performance Steering Wheel with Foot-pedal Control
Comfort
- Armrests:
- adjustable arm rests
- Seat Suspension:
- High-back suspension
Dimensions
- Dimensions:
- L/W/H 80" L x 62" W x 48" H
- Weight (approx.):
- 1000 lbs.
Additional Specifications
- Hour Meter:
- Basic Hour Meter (no tach)
- Discharge Chute:
- High-density, impact-resistant rubber
- Cup Holder:
- Intergrated into Side Pod
- Model Number:
- 53TIEFJU050
- Trans Fluid:
- 490-000-C051 NEED 70.3OZ
Maintenance Parts
- Air Filter:
- KM-11013-7044
- Pre Filter:
- KM-11013-7045
- Oil Filter:
- KM-49065-0721
- Fuel Filter:
- KM-49019-0027 OR 490-240-0001
- Spark Plug:
- KM-BPR4ES
- Deck Belt:
- 954-05015 OR 490-501-C076
- PTO Belt:
- 954-05128
- Drive Belt:
- 954-04317A OR 490-501-C069
- Blades:
- 942-04415 OR 490-110-C163
- Xtreme Blade:
- 02005019-X
- Ignition Key:
- 925-06908
- Trans Filter:
- PH-52114P
- Engine Oil:
- 490-000-C044
Key Features
- 23.5HP Kawasaki FX730v
- 60-inch 10-gauge steel commercial deck with top, bottom and side reinforcements for added durability
- 12cc commercial-grade transmission ensures optimal blade tip speed and superior quality of cut at speeds up to 9.5 mph
Product Manuals
No confirmed manuals are currently available for this product. Browse all product manuals or ask our team.
